Cat7 SFTP Solid CU 305M

Category:

Description

NaviaTec Cat7 SFTP Solid CU 305M

NaviaTec CAT7 Cable Indoor SFTP shielded pairs Solid Installation Cable

Color: Gray
Screen Type: SFTP PIMF
Enclosure Type: PVC halogen free LSZH jacket
Category: Cat7
Conductor: 23 AWG Solid Bare Copper
Cable Type: Solid Installation Wire
Cable Length: 305m on wood spool
Total # of insulated conductors: 8 Conductors, twisted in 4 pairs
Color Code: White-Blue/Blue, White-Orange/Orange, White-Green/Green, White-Brown/Brown
Overall Diameter: 7.6mm ± 0.5mm
Applications:
10GBase-T Ethernet
1000Base-Tx Gigabit Ethernet
10Base-T, 100Base-TX Fast Ethernet
10 VG – AnyLan
550 MHz Broadband Video
Voice, T1, E1, ISDN
155/622 Mbps ATM

Electrical Characteristics
Impedence: 1-600MHz 100±15(Ohms)
Rated Temperature: 75C
DC Resistance Unbalance(%): Max 2.5
DC Resistance 20C: 8.4(Ohms/100m)
Pair to Ground Capacitance Unbalance: 330(pF/100M)
Insulation Resistance: >5000M*Km
Dielectric strength: DC 2500V 2S.

Application:
Meets or exceeds requirments of ANSI/TIA-568-C2 Category 6 and ISO 11801 2nd Edition Class E channel standards.
Meets or exceeds requirements of ANSI/TIA-568-C.2 and IEC 61156-5 Category 7 component standards.
Meets requirements of IEEE 802.3af and IEEE 802.3at for POE applications.
Third party tested to comply with ANSI/TIA/EIA-568-C.2.

Ordering Info:

Article # EAN Code
NVT-CAT7-SPOOL351 3856016515284
